RO-Tower Technical Specifications
Top Grade Filters & Parts
1st Stage Sediment Pre-Filter (Made in USA) ANSI/NSF Standard 42 & FDA
2nd Stage Activated Carbon (Made in USA) ANSI/NSF Standard 42
3rd Stage Reverse Osmosis Membrane (Made in USA) ANSI/NSF Standard 58
4th Stage Ceramic Filter with Pi-Energy Treatment (Made in England) ANSI/NSF Standard 42 & 53
Fitting Plastic Water Tubing & Push-in Fitting (Made in England) ANSI/NSF Standard 51 & 61
Measurements
Height
1080mm
Width
400mm
Depth
380mm
Hot Tank
3 Litres
Room Temp. Tank
10 Litres
Cold Tank
4 Litres
Hot power
800W
Cold power
210W
Installation Requirements (Outside cabinet)
Water Supply
- 12mm copper pipe
- With switch
Drainage
- Connect to sump tank via 6mm plastic tube; or
- 12mm drain pipe with check valve (if no sump tank); or
- 32mm drain pipe with P-trap
Electrical
- 13A
Installation Diagram
Extra Notes (Installation inside cabinet)
1. Both power socket & water supply switch positions should be reachable and not be blocked by the dispenser
2. Cabinet vent /chimney required for heat release
3. Minimum Clearance – Top 100mm / Left 50mm / Right 50mm / Back 100mm
