RO-E8 Technical Specifications
Top Grade Filters & Parts
1st Stage Sediment Pre-Filter (Made in USA) ANSI/NSF Standard 42 & FDA
2nd Stage Activated Carbon (Made in USA) ANSI/NSF Standard 42
3rd Stage Reverse Osmosis Membrane (Made in USA) ANSI/NSF Standard 58
4th Stage Ceramic Filter with Pi-Energy Treatment (Made in England) ANSI/NSF Standard 42 & 53
Fitting Plastic Water Tubing & Push-in Fitting (Made in England) ANSI/NSF Standard 51 & 61
Measurements
Capacities
Rating
Height
1,350mm
Width
430mm
Depth
480mm
Hot Tank
15 Litres
Warm Temp. Tank
10 Litres
Cold Tank
4 Litres
Hot power
1,100W
Cold power
210W
Installation Requirements (Outside cabinet)
Water Supply
-
12mm copper pipe
-
With switch
Drainage
-
32mm drain pipe with P-trap
-
Drain inlet height must <550mm
-
Drain inlet hole faces upward
Electrical
-
13A
Installation Diagram
Extra Notes (Installation inside cabinet)
1. Drain inlet must be at the left or right of dispenser; and be reachable for repair.
2. Both power socket & water supply switch positions should be reachable and not be blocked by the dispenser.
3. Cabinet vent /chimney required for heat release
4. Minimum Clearance – Top 100mm / Left 50mm / Right 50mm / Back 100mm
5. No step inside the cabinet
